150A 3P IP65 Industrial Waterproof UKP Isolator Switch IEC standard
This is a rotary switch disconnector, for line connection is disconnected and isolated line maintenance or maintenance load. A support portion comprising a movable contact, drive means, stationary contact, the housing, the wire holder, the base, since the helical gear, to achieve dynamic and static contact closing and opening configuration, while using as a spiral spring energy storage spring , Can ensure fast closing and opening speed. The product has good stability and strong on-off capability. In addition, this product not only allows the operator to clearly see the opening and closing of the moving and static contacts, but also prevents unrelated personnel from accidentally closing and closing. It has the advantages of reasonable design, ingenious, safe and reliable, convenient and practical, and excellent performance.
| Brand Name | KRIPAL |
| Model Number | UKP0/1/3/5 |
| Type | Load Isolation Switch |
| Number of poles | 3P,4P |
| Current | 10A,16A,20A,25A,32A,40A,50A,63A,80A,100A,125A,150A |
| Frequency | 50/60Hz |
| Protection | IP65 |
| Material | PC,Copper |
| Standard | IEC/EN 60947-3, AS/NZS 3947 |
| Identification | VDE,SEMKO,CE CERTIFICATE,CB TEST REPORT |
| Warranty | One and a half years |
Reference Model
| Current(A) | Rated Voltage(V) | Model | |
| 3P | 4P | ||
| 63 | 230-440V | UKP5-363 | UKP5-463 |
| 80 | 230-440V | UKP5-380 | UKP5-480 |
| 100 | 230-440V | UKP5-3100 | UKP5-4100 |
| 125 | 230-440V | UKP5-3125 | UKP5-4125 |
| 150 | 230-440V | UKP5-3150 | UKP5-4150 |
Maintenance switch
Ioad Isolation switch UKP can be used as maintenance switch or main switch with enclosure,connecting kinds of electric loads.Several padlocks can be assembled in the opening position,in order to ensure personnel safety,the opening position shall be clear and can not reset automatically.
This safety switch conforms to standards IEC 60947-3 and GB14048.3
Proper installation ways
①Surface installation(insulation enclosure assembled)
②Parallel and level installation(fix in front of it)
③Rear installation(fix at the back of it,door linkage or cover linkage)
1.Safe and Reliable: the terminals equipped with protective cover conform to VDE0106,to ensure the safety of finger touch
2.Flexible application:800 standard contact combinations are available,with an almost unlimited number of switch combinations.
3.The full range: According to the classification power capacity, can provide the most economical solution for different projects; nameplate There are many different methods of installation, flexibility to meet the needs of specific applications.
4.It has a variety of uses in industrial machinery and equipment.For example,when used as maintenance switch and insurance switch,3 padlocks can be installed in O part to ensure the personal safety of users.
Waterproof isolator switches offer ideal features for their use as: ON-OFF Switches, Emergency-Off Switches, Maintenance Switches, Safety Switches, Distribution Switches, and Motor switches.
| Lead Time | Normally 20 days after received your fund, but mostly depends on your quantity |
| Leading Port | Ningbo or Shanghai by sea or by air. If any other loading port please kindly advise and the extra inland transportation freight will be added accordingly. |
| Trade Term | EXW, FOB, CIF as customer need |
| Payment Term | T/T 30% as deposit,and 70% before delivery. |
| Packaging | Neutral carton, or according to customer requirements |
| Shipping | By Air, by sea, by express |
1. Strong production capacity and strict quality control system;
2.OEM & ODM are available; there is an our own mould tooling center in KRIPAL factory;
3. Well-trained and experienced staffs to answer all your inquires;
4. After-sale tracking service for all of our clients;
5.Your inquiry and problems related to our products or prices will be replied in 24 hours.
Zhejiang kripal Electric Co., Ltd. was founded in 1992, and now has two production bases, Yueqing in Wenzhou and Xianju in Taizhou. The company has more than 500 employees, including over 10 senior engineers, 30 professional technicists and 30 senior executives, covering an area of more than 15000 square meters. The company has passed ISO9001 quality system certification, and serves customers with high-quality service, innovative electrical solutions and competitive prices. Therefore, the products are exported to Europe, Australia, America, Africa, Oceania, Southeast Asia, Hong Kong, Macao and Taiwan, with good brand effect in the local area, and won the title of Zhejiang export famous brand enterprise. Our mission is to strive to realize the dream of professional electrical world brand, and strive to improve our company's share in the global market. Welcome to cooperate with kripal to create a better tomorrow.
